| Nazwa marki: | SCXK |
| Numer modelu: | P2.5 |
| MOQ: | 5 m2 |
| Cena £: | negocjowalne |
| Warunki płatności: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Możliwość zaopatrzenia: | 5000 m2 miesięcznie |
| Parameter | Specification |
|---|---|
| Model | Indoor SMD P2.5 |
| Lamp Size | 2121 |
| Resolution | 2.5mm |
| Pixel Configuration | RGB 3 in 1 |
| Pixel Density | 160,000 pixels/m² |
| Module Resolution | 64x64 |
| Module Size | 160x160mm |
| Viewing Distance | ≥0.5m |
| Brightness Adjustment | Single point adjustable |
| Color Adjustment | Single point adjustable |
| White Balance Brightness | >2500cd/㎡ |
| Color Temperature | 6500K-9500K |
| Viewing Angle | 140° horizontal & vertical |
| Signal Processing | 10 or 14 bit |
| Grey Processing | 1024/16834/65536 levels |
| Control Distance | Internet: 100m, Multimode: 500m, Single: 5km |
| Driving Mode | Constant current |
| Scanning Mode | 1/16 |
| Frame Rate | 60Hz |
| Refresh Frequency | >4200Hz |
| Control Mode | Computer synchronous |
| Brightness Adjustment Range | Manual/automatic, 255 steps without grey loss |
| Out of Control Rate | <1/10000 |
| Working Hours Test | ≥72 hours |
| MTBF | >5000 hours |
| Lifetime | 100,000 hours |
| White Lifetime | 50,000 hours (brightness halving) |
| Operating Temperature | -20°C to 45°C |
| Storage Temperature | -30°C to 65°C |
| Maximum Power | <1000W/㎡ |
| Average Power | <280W/㎡ |
| Self-check Technology | LED spot, communications, power, temperature monitoring |
| Remote Monitoring | Supervision, fault recording, warning systems |
| Software Environment | Windows NT, 1999, XP |
| Brightness Uniformity | <10% |
| Color Uniformity | ±0.003 chromaticity coordinate |
| Power Supply | AC85-264V (50Hz-60Hz) |
| Contrast Ratio | 1000:1 |
| System Protection | Moisture, dust, temperature, corrosion, burn, static, vibration |
| Operating Humidity | 10-95% |
| Storage Humidity | 10-95% |
